Comunicación I2C

Comunicación mediante la interfaz I2C

I2C, o circuito interintegrado, es una interfaz de chip a chip que admite la comunicación de dos cables. Puede conectarse a dispositivos periféricos I2C y leer y escribir en ellos. Cree el objeto de interfaz utilizando la función device con un objeto aardvark o ni845x.

Para utilizar la interfaz I2C, debe tener instalado un adaptador de host Total Phase^® Aardvark I2C/SPI™ o un dispositivo de interfaz I2C/SPI USB-8451 o USB-8452 NI™.

Funciones

expandir todo

Descubra y conéctese

`aardvarklist`	List available Total Phase Aardvark controllers (desde R2023a)
`aardvark`	Total Phase Aardvark Adapter connection (desde R2023a)
`aardvarkfind`	Find Total Phase Aardvark controllers (desde R2024a)
`ni845xlist`	List available NI USB-845x controllers (desde R2023a)
`ni845x`	NI USB-845x connection (desde R2023a)
`ni845xfind`	Find NI USB-845x connections (desde R2024a)
`scanI2CBus`	Scan for I2C peripheral devices connected to controller board (desde R2023a)
`device`	I2C peripheral device connection (desde R2023a)

Configurar y comunicarse con pines DIO

`configureDigitalPin`	Set digital pin mode on controller (desde R2023a)
`readDigitalPin`	Read logic level value of digital pin on controller (desde R2023a)
`writeDigitalPin`	Write logic level value to digital pin on controller (desde R2023a)

Comunicarse con dispositivos periféricos I2C

`read`	Read data from I2C peripheral device (desde R2023a)
`write`	Write data to I2C peripheral device (desde R2023a)
`readRegister`	Read data from I2C peripheral device register (desde R2023a)
`writeRegister`	Write data to I2C peripheral device register (desde R2023a)

Temas

I2C Interface Overview
Connect to I2C controller boards and peripheral devices and communicate with them from MATLAB^®.
Configure I2C Controller Board Communication
Discover and connect to Total Phase Aardvark™ or NI USB-845x controller boards using the aardvark or ni845x interface.
Transmit Data to Peripheral Device Over I2C Interface
Communicate with an I2C peripheral device connected to a Total Phase Aardvark or an NI USB-845x controller board.
Install Instrument Control Toolbox Support Package for Total Phase Aardvark I2C/SPI Interface
Install the support package for a Total Phase Aardvark controller to communicate with I2C and SPI interfaces in MATLAB.
Install Instrument Control Toolbox Support Package for National Instruments NI-845x I2C/SPI Interface
Install the support package for an NI USB-845x controller to communicate with I2C and SPI interfaces in MATLAB.
Transition Your Code to aardvark or ni845x Interface
Create I2C connections using the device function with an aardvark or ni845x object instead of i2c.
