Importación de FMU
El bloque FMU permite importar sus aplicaciones, contenidas en FMU, a Simulink. Este bloque tiene dos modos de integrar las FMU que implementa:
Una interfaz de cosimulación FMI. Estas FMU contienen solvers locales.
Una interfaz de intercambio de modelos FMI. Estas FMU no contienen solvers locales.
Bloques
| FMU | Include Functional Mockup Unit (FMU) in model |
Funciones
fmudialog.compileFMUSources | Generate binary for FMU with source code on current platform (Desde R2024a) |
fmudialog.createBusType | Create all FMU bus objects required for structured input or output ports in workspace |
fmudialog.createEnumType | Generate all enumeration classes required for FMU input or output ports |
fmudialog.createTypeObject | Generates enumeration and bus objects required for FMU input or output ports |
Temas
- Import FMUs
Import your FMU to Simulink.
- Implement an FMU Block
Implement a block in Simulink using your FMU.
- FMU Block Calling Sequences
Review calling sequences for Co-Simulation and Model Exchange FMU blocks.
- Debug FMU with Source Code Using External Debugger
Launch external debugger from Simulink to debug FMU with source code.
- Simulate FMU with Linux Binary on Windows (Simulink Compiler)
Simulate standalone cosimulation FMU 2.0 with Linux® binary on Windows®.
Ejemplos destacados
Importar Cosimulación FMU a Simulink
Este ejemplo muestra cómo usar el bloque FMU Import para cargar un archivo FMU. El archivo FMU admite una ejecución en modo de cosimulación. Simulink® admite el avance y retroceso de la simulación, el ajuste de parámetros entre ambas tareas, y el almacenamiento de estados del bloque FMU Import, siempre y cuando el propio FMU admita estas funcionalidades.
Importing a Model Exchange FMU into Simulink
Model showing how to use the FMU Import block to load an FMU file. The FMU file supports execution in Model Exchange mode.
Simplify Interface for Structured Data with FMU Import Block
Use bus signals and structure parameters in an FMU block.
Import and Simulate FMU with Time-Based Clocks in Simulink
Demonstrates the use of a Functional Mockup Unit (FMU) containing time-based clocks in Simulink®. You can import standalone co-simulation FMUs that implement the following types of time-based clocks as defined in the FMI 3.0 standard:
Simulate FMU with Enum Type Ports Using FMU Import Block
The example demonstrates how to use the FMU import block to simulate FMUs that have enumerated data type ports. The FMU import block enables the import of functional mockup units (FMUs) in Simulink®.
Capture Simulation State, Fast Restart, and Step Through Model Containing FMU
Use the internal states of a standalone cosimulation FMU to enhance the simulation capability of a model with fixed-step solver FMU in Simulink®. Internal states of an FMU enables you to stop and resume simulation using model operating points, perform iterative simulation using fast restart, and analyze your model using backward simulation stepping.
