The Powertrain Blockset™ includes blocks for 1DOF and 3DOF vehicle motion. The driving scenario blocks allow you to specify a drive cycle and driver commands. Use the vehicle blocks in fuel economy studies and drive cycle analysis.
Use the Virtual Vehicle Composer app to configure and build a virtual vehicle that you can use for system-level performance analysis, including component sizing, fuel economy, and drive cycle tracking. To get started with your virtual vehicle, see Get Started with the Virtual Vehicle Composer.
|Virtual Vehicle Composer||Configure, build, and analyze a virtual automotive vehicle|
|Vehicle Body 1DOF Longitudinal||Two-axle vehicle in forward and reverse motion|
|Vehicle Body 3DOF Longitudinal||3DOF rigid vehicle body to calculate longitudinal, vertical, and pitch motion|
|Vehicle Body Total Road Load||Vehicle motion using coast-down testing coefficients|
|Motorcycle Chain||Implement motorcycle chain|
|Motorcycle Body Longitudinal In-Plane||Longitudinal in-plane motorcycle vehicle motion|
|Datastore for collection of MDF-files|
|Read data in MDF datastore|
|Read all data in MDF datastore|
|Subset of data from MDF datastore|
|Reset MDF datastore to initial state|
|Determine if data is available to read from MDF datastore|
|Partition MDF datastore|
|Number of partitions for MDF datastore|
- Get Started with the Virtual Vehicle Composer
Use the Virtual Vehicle Composer app to configure, build, and analyze a virtual vehicle.
- Install Drive Cycle Data
Install drive cycle data for the Drive Cycle Source block from a support package.
- Resize Engines and Mapped Motors
Resize engines and mapped motors using the Virtual Vehicle Composer app.
- Track Drive Cycle Errors
Use the Drive Cycle Source blocks to identify drive cycle faults.
