pamdemod

Pulse amplitude demodulation

collapse all in page

Syntax

z = pamdemod(y,M)
z = pamdemod(y,M,ini_phase)
z = pamdemod(y,M,ini_phase,symbol_order)

Description

z = pamdemod(y,M) demodulates the complex envelope y of a pulse amplitude modulated signal. M is the alphabet size. The ideal modulated signal should have a minimum Euclidean distance of 2.

z = pamdemod(y,M,ini_phase) specifies the initial phase of the modulated signal in radians.

z = pamdemod(y,M,ini_phase,symbol_order) specifies how the function assigns binary words to corresponding integers. If symbol_order is set to 'bin' (default), the function uses a natural binary-coded ordering. If symbol_order is set to 'gray', it uses a Gray-coded ordering.

Examples

collapse all

Open Live Script

Modulate and demodulate random integers using pulse amplitude modulation. Verify that the output data matches the original data.

Set the modulation order and generate 100 M-ary data symbols.

M = 12;
dataIn = randi([0 M-1],100,1);

Perform modulation and demodulation operations.

modData = pammod(dataIn,M);
dataOut = pamdemod(modData,M);

Compare the first five symbols.

[dataIn(1:5) dataOut(1:5)]
ans = 5×2

     9     9
    10    10
     1     1
    10    10
     7     7

Verify that there are no symbol errors in the entire sequence.

symErrors = symerr(dataIn,dataOut)
symErrors = 0

Extended Capabilities

C/C++ Code Generation
Generate C and C++ code using MATLAB® Coder™.

Version History

Introduced before R2006a
