# theaterPlot

Plot objects, detections, and tracks in Scenario

## Description

The theaterPlot object is used to display a plot of a trackingScenario. This type of plot can be used with sensors capable of detecting objects.

To display aspects of a scenario on a theater plot:

1. Create a theaterPlot object.

2. Create plotters for the aspects of the scenario that you want to plot.

3. Use the plotters with their corresponding plot functions to display those aspects on the theater plot.

This table shows the plotter functions to use based on the scenario aspect that you want to plot.

Scenario Aspect to PlotPlotter Creation FunctionPlotter Display Function
Sensor coverage areascoveragePlotterplotCoverage
Sensor detectionsdetectionPlotterplotDetection
Object orientationorientationPlotterplotOrientation
PlatformplatformPlotterplotPlatform
TracktrackPlotterplotTrack
Object trajectorytrajectoryPlotterplotTrajectory

## Creation

### Description

tp = theaterPlot creates a theater plot in a new figure.

example

tp = theaterPlot(Name,Value) creates a theater plot in a new figure with optional input Properties specified by one or more Name,Value pair arguments. Properties can be specified in any order as Name1,Value1,...,NameN,ValueN. Enclose each property name in quotes.

## Properties

expand all

Parent axes, specified as a theaterPlot handle. If you do not specify Parent, then theaterPlot creates axes in a new figure.

Plotters created for the theater plot, specified as an array of plotter objects.

Limits of the x-axis, specified as a two-element row vector, [x1,x2]. The values x1 and x2 are the lower and upper limits, respectively, for the theater plot display. If you do not specify the limits, then the default values for the Parent property are used. See Orientation, Position, and Coordinate for coordinate system definitions.

Data Types: double

Limits of the y-axis, specified as a two-element row vector, [y1,y2]. The values y1 and y2 are the lower and upper limits, respectively, for the theater plot display. If you do not specify the limits, then the default values for the Parent property are used. See Orientation, Position, and Coordinate for coordinate system definitions.

Data Types: double

Limits of the z-axis, specified as a two-element row vector, [z1,z2]. The values z1 and z2 are the lower and upper limits, respectively, for the theater plot display. If you do not specify the limits, then the default values for the Parent property are used. See Orientation, Position, and Coordinate for coordinate system definitions.

Data Types: double

Unit of each axes, specified as a three-element string array. Each element must be "m" or "km"

Data Types: string

## Object Functions

expand all

 coveragePlotter Create coverage plotter detectionPlotter Create detection plotter orientationPlotter Create orientation plotter platformPlotter Create platform plotter trackPlotter Create track plotter trajectoryPlotter Create trajectory plotter
 plotCoverage Plot set of coverages in theater coverage plotter plotDetection Plot set of detections in theater detection plotter plotOrientation Plot set of orientations in orientation plotter plotPlatform Plot set of platforms in platform plotter plotTrack Plot set of tracks in theater track plotter plotTrajectory Plot set of trajectories in trajectory plotter
 clearData Clear data from specific plotter of theater plot clearPlotterData Clear plotter data from theater plot findPlotter Return array of plotters associated with theater plot

## Examples

collapse all

Create a theater plot.

tp = theaterPlot('XLim',[0 90],'YLim',[-35 35],'ZLim',[0 50]);

Display radar detections with coordinates at $\left(30,\text{\hspace{0.17em}}-5,\text{\hspace{0.17em}}5\right)$, $\left(50,\text{\hspace{0.17em}}-10,\text{\hspace{0.17em}}10\right)$, and $\left(40,\text{\hspace{0.17em}}7,\text{\hspace{0.17em}}40\right)$. Set the view so that you are looking on the yz-plane. Confirm the y- and z-coordinates of the radar detections are correct.

plotDetection(radarPlotter, [30 -5 5; 50 -10 10; 40 7 40])
grid on
view(90,0)

The view can be changed by opening the plot in a figure window and selecting Tools > Rotate 3D in the figure menu.

## Limitations

You cannot use the rectangle-zoom feature in the theaterPlot figure.
