The analysis of variance technique in Perform One-Way ANOVA takes a set of grouped data and determine whether the mean of a variable differs significantly among groups. Often there are multiple response variables, and you are interested in determining whether the entire set of means is different from one group to the next. There is a multivariate version of analysis of variance that can address the problem.

The `carsmall`

data set has measurements on
a variety of car models from the years 1970, 1976, and 1982. Suppose
you are interested in whether the characteristics of the cars have
changed over time.

Load the sample data.

```
load carsmall
whos
```

Name Size Bytes Class Attributes Acceleration 100x1 800 double Cylinders 100x1 800 double Displacement 100x1 800 double Horsepower 100x1 800 double MPG 100x1 800 double Mfg 100x13 2600 char Model 100x33 6600 char Model_Year 100x1 800 double Origin 100x7 1400 char Weight 100x1 800 double

Four of these variables (`Acceleration`

, `Displacement`

, `Horsepower`

,
and `MPG`

) are continuous measurements on individual
car models. The variable `Model_Year`

indicates the
year in which the car was made. You can create a grouped plot matrix of these
variables using the `gplotmatrix`

function.

Create a grouped plot matrix of these variables using the gplotmatrix function.

```
x = [MPG Horsepower Displacement Weight];
gplotmatrix(x,[],Model_Year,[],'+xo')
```

(When the second argument of `gplotmatrix`

is
empty, the function graphs the columns of the `x`

argument against each other, and places histograms along
the diagonals. The empty fourth argument produces a graph with the
default colors. The fifth argument controls the symbols used to distinguish
between groups.)

It appears the cars do differ from year to year. The upper right
plot, for example, is a graph of `MPG`

versus `Weight`

.
The 1982 cars appear to have higher mileage than the older cars, and
they appear to weigh less on average. But as a group, are the three
years significantly different from one another? The `manova1`

function can answer that question.

[d,p,stats] = manova1(x,Model_Year)

d = 2

p =2×110^{-6}× 0.0000 0.1141

`stats = `*struct with fields:*
W: [4x4 double]
B: [4x4 double]
T: [4x4 double]
dfW: 90
dfB: 2
dfT: 92
lambda: [2x1 double]
chisq: [2x1 double]
chisqdf: [2x1 double]
eigenval: [4x1 double]
eigenvec: [4x4 double]
canon: [100x4 double]
mdist: [1x100 double]
gmdist: [3x3 double]
gnames: {3x1 cell}

The `manova1`

function produces
three outputs:

The first output,

`d`

, is an estimate of the dimension of the group means. If the means were all the same, the dimension would be 0, indicating that the means are at the same point. If the means differed but fell along a line, the dimension would be 1. In the example the dimension is 2, indicating that the group means fall in a plane but not along a line. This is the largest possible dimension for the means of three groups.The second output,

`p`

, is a vector of*p*-values for a sequence of tests. The first*p*value tests whether the dimension is 0, the next whether the dimension is 1, and so on. In this case both*p*-values are small. That's why the estimated dimension is 2.The third output,

`stats`

, is a structure containing several fields, described in the following section.

The `W`

, `B`

, and `T`

fields
are matrix analogs to the within, between, and total sums of squares
in ordinary one-way analysis of variance. The next three fields are
the degrees of freedom for these matrices. Fields `lambda`

, `chisq`

,
and `chisqdf`

are the ingredients of the test for
the dimensionality of the group means. (The *p*-values
for these tests are the first output argument of `manova1`

.)

The next three fields are used to do a canonical analysis. Recall that in principal components analysis (Principal Component Analysis (PCA)) you look for the combination of the original variables that has the largest possible variation. In multivariate analysis of variance, you instead look for the linear combination of the original variables that has the largest separation between groups. It is the single variable that would give the most significant result in a univariate one-way analysis of variance. Having found that combination, you next look for the combination with the second highest separation, and so on.

The `eigenvec`

field is a matrix that defines
the coefficients of the linear combinations of the original variables.
The `eigenval`

field is a vector measuring the ratio
of the between-group variance to the within-group variance for the
corresponding linear combination. The `canon`

field
is a matrix of the canonical variable values. Each column is a linear
combination of the mean-centered original variables, using coefficients
from the `eigenvec`

matrix.

c1 = stats.canon(:,1); c2 = stats.canon(:,2);

Plot the grouped scatter plot of the first two canonical variables.

```
figure()
gscatter(c2,c1,Model_Year,[],'oxs')
```

A grouped scatter plot of the first two canonical variables
shows more separation between groups then a grouped scatter plot of
any pair of original variables. In this example, it shows three clouds
of points, overlapping but with distinct centers. One point in the
bottom right sits apart from the others. You can mark this point on
the plot using the `gname`

function.

Roughly speaking, the first canonical variable, `c1`

,
separates the 1982 cars (which have high values of `c1`

)
from the older cars. The second canonical variable, `c2`

,
reveals some separation between the 1970 and 1976 cars.

The final two fields of the `stats`

structure
are Mahalanobis distances. The `mdist`

field measures
the distance from each point to its group mean. Points with large
values may be outliers. In this data set, the largest outlier is the
one in the scatter plot, the Buick Estate station wagon. (Note that
you could have supplied the model name to the `gname`

function
above if you wanted to label the point with its model name rather
than its row number.)

Find the largest distance from the group mean.

max(stats.mdist)

ans = 31.5273

Find the point that has the largest distance from the group mean.

find(stats.mdist == ans)

ans = 20

Find the car model that corresponds to the largest distance from the group mean.

Model(20,:)

ans = 'buick estate wagon (sw) '

The `gmdist`

field measures the distances between
each pair of group means. Examine the group means using `grpstats`

.

grpstats(x, Model_Year)

ans =3×410^{3}× 0.0177 0.1489 0.2869 3.4413 0.0216 0.1011 0.1978 3.0787 0.0317 0.0815 0.1289 2.4535

Find the distances between the each pair of group means.

stats.gmdist

`ans = `*3×3*
0 3.8277 11.1106
3.8277 0 6.1374
11.1106 6.1374 0

As might be expected, the multivariate distance between
the extreme years 1970 and 1982 (11.1) is larger than the difference
between more closely spaced years (3.8 and 6.1). This is consistent
with the scatter plots, where the points seem to follow a progression
as the year changes from 1970 through 1976 to 1982. If you had more
groups, you might find it instructive to use the `manovacluster`

function
to draw a diagram that presents clusters of the groups, formed using
the distances between their means.
