Explore, Pick, Iterate: Three Steps for Antenna Design

Use the Antenna Designer app to rapidly design an antenna for your wireless application. In a few steps, choose from an extensive catalogue of antennas based on your specifications. Design and accurately analyze the antenna using the full wave Method of Moments. You don’t need to be an EM expert to solve the antenna problem.

In just a few seconds, visualize and interactively inspect the antenna impedance, current, and radiation pattern. Rapidly iterate on the antenna geometrical and electrical properties to explore alternatives until you meet the requirements. Generate a MATLAB^® script to share and further optimize your design. Antenna design has never been easier.
